Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof [206-051S]

$27.78 $34.95

🛡️ Lifetime Parts Guarantee

We’ve got your back: For real, For life. Learn More

Free Shipping On All Orders!

(Normally)In stock items ship same or next business day from the closest of our 20 warehouses with stock. $6.99 flat rate, or free over $100.

Phone Support (856) 666-7986

Call us with questions 9-5 Monday - Friday.

(856) 666-7986

No Fee Returns for 30 Days

Call us with questions 9-5 Monday - Friday.

(856) 666-7986

Description

Panel Seal/Waterproof "A" Frame Magnetic Circuit Breakers


  • Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
  • Meets all American Boat and Yacht Council (ABYC) Standards for non-ignition protected circuit breakers
  • UL Recognized (UL 1077) for use in th USA, and CSA Certified for use in Canada
  • Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
  • Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
  • Handle Color - Metal with silicon rubber seal
  • Maximum Aperage - 50 Amps
  • Maximum Voltage/AIC - 32 VDC/2,500 amps with no back-up fuse (ABYC E-11.10.1.5.5)
  • Rated Switch Cycles - 10,000 actuations at rated current and voltage
  • Electrical Hardware - Hex nut 1/2-32 (supplied with circuit breaker); Lockwasher 1/2" internal tooth (supplied with circuit breaker)
  • Optional Boot - Black silicone rubber (P/N 048-015)

    Specifications:

    • Color: Stainless
    • Throw/Pole: SPST
    • Box Dimensions: 2"H x 2"W x 2"L WT: 0.2 lbs
    • UPC: 602290201404
