Lumitec Nautilus Piling Light - Spectrum RGBW/Warm White - Stainless Steel Housing [101670]
- Ships same or next business day.
🛡️ PARTSDUCK Promise - Best price, great support & more
🛡️ PARTSDUCK Promise - Best price, great support & more
More than just a price match! Best price, fast shipping, great stock, real support. More Here
Free Shipping Over $99
Free Shipping Over $99
In stock items ship same or next business day from the closest of our 20+ warehouses with stock. Economy Shipping is free over $99.
Phone Support (856) 666-7986
Phone Support (856) 666-7986
Call us with questions 9-5 Monday - Friday EST.
(856) 666-7986
No Fee Returns for 30 Days
No Fee Returns for 30 Days
No restocking fees on most items, full Return Policy
Lumitec Nautilus Piling Light - Spectrum RGBW/Warm White - Stainles...
Description
Description
Nautilus Piling Light - Spectrum with Warm White
Above-water accent lighting for pilings, posts and wall-wash applications. Confirm the selected color version and compatible power/control system before adding it to a dock installation.
Selection and control
- Light output: Spectrum RGBW - Warm White.
- Housing / finish: Stainless Steel.
- Power supply: 10-30 vDC.
- PLI-enabled for compatible Poco digital control. A compatible Poco module is required for digital control and is not implied to be included with a light fixture.
- Supports Lumitec TTP switch control. Follow the model-specific instructions for the switching sequence.
Specifications
| Color Output | Spectrum RGBW - Warm White |
|---|---|
| Finish / Housing | Stainless Steel |
| Lumens | 255 |
| Voltage | 10-30 vDC |
| 12v DC Amps | 440mA |
| 24v DC Amps | 240mA |
| Rated power | 5.2W |
| White color temperature (CCT) | 3000 K |
| Color Rendering Index (CRI) | 80+ |
| Height | 4.2 in |
| Width | 1.6 in |
| Depth | 1.5 in |
| IP Rating | IP67 |
| PLI Enabled | Yes |
| Timed Toggled Protocol (TTP) | Yes |
| Third Party Dimmer Compatibility (3PD) | Yes |
| Color Match Commitment (CM) | Yes |
| CE Certified | Yes |
| UL Certified | No |
Lumen ratings refer to white-light output where applicable; they do not describe the brightness of every color.
Part identification
- Manufacturer part number: 101670
- PartsDuck SKU: PD-87624
- UPC: 089300016706
Application and installation planning
Nautilus is intended for piling, post and wall-wash illumination. Its supplied mounting adapter accommodates curved or flat locations, with warm-white or Spectrum versions available.
Check the mounting dimensions and wiring access against the actual installation. Size supply wiring and protection for the complete circuit, using the exact model instructions and suitable marine installation practices.
What is included?
The selected Nautilus fixture with its adapter for curved or flat mounting locations.
Common questions
Can I use it away from a Kraken system?
Lumitec supports compatible 12–24V DC power arrangements as well as Mantis or Kraken installations. Check the exact model voltage and control requirements before connecting it.
Do I need Poco for basic operation?
This model supports TTP switch control as well as compatible Poco digital control. Follow the exact model’s switching instructions; a Poco module is needed for the digital-control option.
Can I use an external dimmer?
The manufacturer marks third-party dimmer compatibility as Yes for this model. Confirm the dimmer type, voltage and load requirements in its instructions before selecting one.
Manufacturer warranty
Lumitec states that products purchased from January 1, 2025 onward carry a five-year limited manufacturer warranty for the original purchaser. Earlier purchases retain their applicable original coverage. Keep proof of purchase and obtain a return authorization before a warranty return. Coverage terms and exclusions are available from Lumitec warranty support.
Documents and support
Manufacturer installation resources
Older instruction sheets may show the warranty terms in effect when they were printed. See the current manufacturer warranty policy above for purchase-date coverage.
