Lumitec Javelin 600X Underwater Light [101705]

Javelin 600X Underwater Light

A rectangular underwater light with a polished housing and RGBW output. Intended for surface mounting; use the Javelin-specific template and instructions rather than a round SeaBlaze cutout.

Selection and control

• Light output: Spectrum RGBW.
• Housing / finish: Polished.
• Power supply: 10-30 vDC.
• PLI-enabled for compatible Poco digital control. A compatible Poco module is required for digital control and is not implied to be included with a light fixture.
• Supports Lumitec TTP switch control. Follow the model-specific instructions for the switching sequence.
• Lumitec does not specify this model for third-party dimmer control.

Specifications

Lumen ratings refer to white-light output where applicable; they do not describe the brightness of every color.

Part identification

• Manufacturer part number: 101705
• PartsDuck SKU: PD-92801
• UPC: 089300017055

Application and installation planning

Javelin uses a rectangular, polished housing for a contemporary underwater-light installation. Lumitec positions the range for freshwater boats while also supporting saltwater applications.

Use the linked Javelin installation guide for the correct mounting and wiring configuration. Plan the wiring run, circuit protection and access for installation before drilling or connecting power.

Lumitec recommends transom placement approximately 6–12 inches below the waterline, clear of engines and trim tabs. These surface-mount lights are not recommended for running surfaces. Water conditions and light spacing affect the visible result.

What you are ordering

This listing supplies the exact Lumitec item identified in the part identification section. Use the product identification and specifications to distinguish it from other sizes, finishes and output versions.

Common questions

Can I reuse a round-light mounting template?
No. Use the Javelin template and verify the cable passage, fastener locations and clearances before drilling.

Do I need Poco for basic operation?
This model supports TTP switch control as well as compatible Poco digital control. Follow the exact model’s switching instructions; a Poco module is needed for the digital-control option.

Can I add a conventional third-party dimmer?
The exact manufacturer specification marks third-party dimmer compatibility as No. Use the supported control method for this model.

Manufacturer warranty

Lumitec states that products purchased from January 1, 2025 onward carry a five-year limited manufacturer warranty for the original purchaser. Earlier purchases retain their applicable original coverage. Keep proof of purchase and obtain a return authorization before a warranty return. Coverage terms and exclusions are available from Lumitec warranty support.

Documents and support

Lumitec Javelin Guide — mounting, wiring and troubleshooting

• Lumitec product specifications
• Lumitec 2026 product guide (PDF)
